Features
Structure
Geometrical Characteristics
| Cable Type | 72 | 96 |
| Cable Dimension (mm) | 13 | 11.5 |
| Fiber Ribbon Number | 6 | 12 |
| Cable Weight(kg/km) | 126 | 120 |
| Coloring Fiber Diameter(μm) | 260±5 | |
Mechanical Characteristics
| Tensile strength (N) | Long Term | 200 |
| Short Term | 660 | |
| Crush resistance（N/100㎜） | Long Term | 200 |
| Short Term | 1000 | |
| Bending Radius(CM) | Dynamic | 20×D (D: Cable Diameter) |
| Static | 10×D (D: Cable Diameter) |
Fiber Type
| Fiber Type(core/cladding dimension) | 9/125 |
Transmission Characteristics
| SMF | |
| 1310/1550(nm) | |
| Attenuation(dB/km) | ≤0.40/0.30 |
| Minimum Bandwidth(MHz·km) | —— |
Environmental Characteristics
| Storage Operating Temperature | -20℃～+60℃ |
