Features
Structure
Geometrical Characteristics
| Cable Type | φ3.0 | φ2.0 |
| Cable Diameter(mm) | 2.85±0.1 | 1.95±0.1 |
| Cable Weight(kg/km) | 6.5 | 3.2 |
| Loose Tube Diameter(μm) | 900±50 | |
Mechanical Characteristics
| Tensile strength (N) | Long Term | 60 |
| Short Term | 100 | |
| Crush resistance（N/100㎜） | Long Term | 100 |
| Short Term | 500 | |
| Bending Radius(CM) | Dynamic | 20×H (H: Cable Axis) |
| Static | 10×H (H: Cable Axis) |
Fiber Type
| Fiber Type(core/cladding dimension) | 9/125, 50/125, 62.5/125 |
Transmission Characteristics
| SMF | 50/125 | 62.5/125 | |
| 1310/1550(nm) | 850/1300(nm) | 850/1300(nm) | |
| Attenuation(dB/km) | ≤0.40/0.30 | ≤3.5/1.5 | ≤3.5/1.5 |
| Minimum Bandwidth(MHz·km) | —— | ≥400/400 | ≥160/500 |
Environmental Characteristics
| Storage Operating Temperature | -20℃～+60℃ |
