12 Fibers FTTH Box NSTB-P-112

This FTTH box is widely used in FTTx projects.

Product Description

[tribulant_slideshow gallery_id=”23″]

12 Fibers FTTH Box outdoor/indoor

Description

The FTTH box NSTB-P-112 provides a high density wall mounted solution for next generation networks, which aims to provide and manage maximum numbers of fiber termination in a limited space. It is normally installed in the way of wall mounting or pole mounting.

Specification

  • Dimension: 260(W)*220(H)*87(D)mm
  • Material: High quality PC material
  • IP54 grade
  • Suitable for SC and LC Duplex adapter
  • Suitable for indoor and outdoor use
  • Work Temperature: -40 ⁰C ~+85 ⁰C
  • Relative Humidity: ≤ 85% (+30 ⁰C)
  • Atmospheric Pressure: 70Kpa~106Kpa
  • Insertion Loss: ≤2dB
  • Return Loss: UPC ≥ 50dB APC ≥ 60dB
  • Insert and Pull out Life: ≥ 1000 times



Accessories

  • Heat-shrink protective sleeves: 12 pcs
  • Expansion screws: 4 sets
  • Nylon tie: 6 pcs
  • Labeling paper: 1pc
  • Key: 1 pc
