Specifications
- Interface RJ45 Ports: 10/100BaseT(X) auto connection, Full /Half duplex or force work mode, and support MDI/MDI-X connection
- Standard：IEEE802.3, IEEE802.3x, IEEE802.3u
Forwarding and Filtrate Rate: 148810pps
Transmit type: Store and Forward switching process type
Support 1K MAC Address - Power
Input Voltage: 12VDC~36VDC,
Overload Current Protection
Connection: 3 bit terminal block - Mechanical
Dimensions (L×W×H): 103 mm*78mm*32mm
Packaging: IP40 Protection, Metal case
Weight : 260g - Environmental
Operating Temperature: -40 to 85°C
Storage Temperature: -45 to 85 °C
Ambient Relative Humidity: 5% to 95% (non-condensing) - Standards
EMI: FCC Part 15, CISPR (EN55022) class A
EMS: EN61000-4-2 (ESD), Level 4
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 4
EN61000-4-5 (Surge), Level 4
EN61000-4-6 (CS), Level 3
EN61000-4-8, Level 5
Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Warranty: 5 years
Certificates: FCC,CE, RoHS approvals
