10/100/1000M Optical Switch 2*SFP +2*10/100/1000M UTP

The optical switch is an L2 function Gigabit Media converter with the switch function. It is equipped with 2 Gigabit TP ports that accommodate optional 10/100/1000Base-T, and 2 fiber ports with 1000M SFP.

Product Description

[tribulant_slideshow gallery_id=”46″]

Description

The optical switch is an L2 function Gigabit Media converter with the switch function. It is equipped with 2 Gigabit TP ports that accommodate optional 10/100/1000Base-T, and 2 fiber ports with 1000M SFP. All ports support the functions of full wire-speed non-blocking switch and interface AUTO-MDI/MDIX, also support up to 1k of the MAC address and VLAN. It complies with the standard of IEEE 802.3 ,IEEE 802.3x, IEEE 802.3u , IEEE 802.3z ,IEEE 802.3ab, which greatly increase the flexibility and reduces the cost of network’s establishment.

In the aspect of interfaces , each port is MDI/MDI-X self-adaptive, can support auto-negotiation of Half/full-Duplex and transmission rate supporting 10M Full/Half Duplex, 100M Full/Half Duplex & 1000M Full-Duplex. Furthermore, each port supports the functions of full wire-speed non-blocking switch. It also supports the back pressure flow monitoring on Half-Duplex and IEEE 802.3x flow control monitoring in Full-Duplex. It has become the best choice of Gigabit Desktop Access in the enterprise , Cybercafe, community ,and campus network’s establishing.

Features

  • 1.25G at fiber port ,10/100/1000M self-adaptive at Ethernet ports, Half/Full-Duplex self-adaptive
  • About 1k MAC address capacity , update antomatically
  • Support broadcast storm protection
  • The max-rate data transmission(wire-speed): 14888000 frm/s(1000M),148800 frm/s(100M),14880 frm/s(10M)
  • Support up to 10KB jumbo frames
  • Support store-and-forward working Mode; support Half/Full Duplex; support 802.3x flow control under Full Duplex working mode; support auto-sensation of MDI/MDIX
  • Network line status LED: transmission rate indicator(10/100/1000M); Fiber and twisted-pair’s connection and data transmission status
  • Support 4 Ethernet ports’ communication simultaneously, using for connecting NIC, switch ,and HUB
  • High-capacity network caching technology ensures data transmission and multimedia applications
  • Support Volume Balancing , Isolating conflicts & Error Detection (CTC), realizing the function of non-blocking switch ,ensuring data-transmission’s security and stability
  • High-degree of electromagnetic shielding properties and good electromagnetic compatibility
  • FCC ,15 CLADD and CE Certification

Parameter

Specification

Standard IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T ,IEEE802.3z 1000Base-SX/LX Gigabit Ethernet
Wavelength 850nm/1310nm/1550nm
Distance 100M SFP  multi-mode:2Km

            Single-mode:20/40/60/80/100/120Km

1000M SFP  multi-mode:220m fiber 62.5/125μm)/ 550m(fiber 50/125μm)

            Single-mode:10/20/40/60/80/100/120Km
Cat5:100m

Port 2 SFP fiber ports: 100Mbps or 1000Mbps

2 Gigabit Combo port:1 Gbps, 1000M SFP&10/100/1000M RJ45

MAC 8K
Buffer memory space 1Mbit
Bit error rate <1/1000000000
MTBF 100000 hours
Power DC12V/2A
Power consumption 10W
Working

temperature

-10~60
Storage temperature -10~55
Humidity 5%~90% non-condensing
Dimension 177mm (L)×111mm(W)×33mm (D)
